Extrusion of a half-inch diameter hose on tuber

  • Circa 1949

Rights

Public Domain

Download selected image

PDFSmall JPG1200 x 1000px — 188 KBLarge JPG2880 x 2400px — 777 KBFull-sized JPG4324 x 3604px — 1.4 MBOriginal fileTIFF — 4324 x 3604px — 44.7 MB
View
Public
Domain
PDF
Download PDF

View of a worker holding a piece of rubber tubing as it is extruded from the tuber machine in the Naval Air Experimental Station's Rubber Compounding and Processing Laboratory. This tuber, a variable speed H.P. Royle equipped with a side-delivery head, was used to extrude rubber or rubber-like materials in the form of a rod or tubing up to a half-inch in diameter. The machine could also be used to apply insulation to wire. This photograph was included in a 1949 Naval Air Experimental Station report on compounding rubber.

Creator of work
Format
Genre
Extent
  • 8 in. H x 10 in. W
Subject
Rights Public Domain Mark 1.0
Credit line
  • Courtesy of Science History Institute

Institutional location

Department
Collection
Physical container
  • Box 1

View collection guide View in library catalog

Related Items

Cite as

Naval Air Experimental Station, and United States. Navy. “Extrusion of a Half-Inch Diameter Hose on Tuber,” circa 1949. Photographs from the Papers of J. Hartley Bowen, Box 1. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/m900nt438.
